Ducati 749R User Manual

E
71
Stop light (fig. 72)
To replace the stop and parking light bulbs, unscrew the
two screws (1) that secure the cover (2). The cover (2) has
two retaining pins on the inner face that hold the tail light
lens (3) in place. Remove the cover (2) from its seat and
remove the tail light lens (3). The bulb is of the bayonet-
type: press and twist anti-clockwise to remove. Fit the
spare bulb by pressing and turning clockwise until it
locates into its seat with an audible click. Refit any parts
you have removed.
Number plate light (fig. 73)
To expose the number plate light bulb, unscrew the two
retaining screws (4) securing the cover (5). Extract the bulb
and replace.
3
2
5
1
4
fig. 72
3
fig. 73

Ducati 749R Specifications

General

Bore x Stroke	94 mm x 54 mm
Transmission	6-speed
Frame	Tubular steel trellis frame
Exhaust	2-1-2 system with catalytic converter and lambda probe
Final Drive	Chain; front sprocket 15; rear sprocket 39
Front Wheel Travel	120 mm
Front Brakes	2 x 320 mm semi-floating discs, 4-piston calipers
Rear Brakes	245 mm disc, 2-piston caliper
Front Tyre	120/70 ZR17
Rear Tyre	180/55 ZR17
Engine Type	L-Twin cylinder, 4 valve per cylinder desmodromic
Power	89 kW (121 hp) @ 10, 250 rpm
Torque	84 Nm (62 lb-ft) @ 8, 500 rpm
Fuel Injection	Electronic fuel injection, 54 mm throttle bodies
Front Suspension	43 mm upside-down fork
Rear Suspension	Fully adjustable monoshock
Rear Wheel Travel	128 mm
Wheelbase	1, 420 mm
Fuel Capacity	15.5 L (including 3.5 L reserve)
