Throttle cable tension adjustment
The throttle twistgrip must have a free play of
1.5-20 mm measured at the edge of the twistgrip,
at all positions of the handlebars. If needed, adjust using
the adjusters (1 and 2, fig. 60) located on the steering tube
on the left side of the motorcycle.
The adjuster (1) is for throttle opening, whereas adjuster
(2) is for throttle closing.
Slip off the dust covers of the adjusters and slacken the
locknuts. Work the adjusters as follows: turn clockwise to
increase play, anti-clockwise to decrease play. When
finished, tighten the locknuts and refit the dust covers.
1,5÷2 mm
1,5÷2 mm
➤
➤
fig. 59
2
1
fig. 60
