E
89
Legend of the wiring diagram of electric system/
injection
1) Right switch.
2) Key-operated switch.
3) Left electric fan
4) Right electric fan
5) Starter motor
6) Starter contactor
7) Battery
8) Regulator fuse
9) Regulator
10)Generator
11)Rear right-turn indicator
12)Tail light
13)Number plate light
14)Rear left-turn indicator
15)Fuel tank
16)Injection fuses
17)Injection relay
18)Self-diagnostics
19)Horizontal cylinder coil
20)Vertical cylinder coil
21)Horizontal cylinder spark plug
22)Vertical cylinder spark plug
23)Horizontal cylinder injector
24)Vertical cylinder injector
25)Throttle position sensor
26)Rpm/timing sensor
27)Coolant temperature sensor
28)Speed sensor
29)Side stand
31)Neutral switch
32)Oil pressure switch
33)Rear stop light switch
34)Ignition/injection unit
35)Fuses
36)Clutch switch
37)Front stop light switch
38)Left switch.
39)Transponder antenna
40)Air temperature sensor
41)Finish line
42)Instruments
43)Lights relay
44)Front left-turn indicator
45)Headlamp
46)Front parking light
47)Front right-turn indicator
48)Warning horn
