Chapter 2 Basic Operation
8
Set [Pickup Air] by following the same procedures as step 4 to 7.
Setting range: 20 to 99
Refer to “Air Adjustment Table” for appropriate volume of [Pickup Air].
9
Press the key.
Returns to the top screen.
Also use the menu key to return to the top screen when [Air Adjust] is set in the idling state.
Air Adjustment Table
The air adjustment table is a guide to set numerical values. The setting range of each setting is the following
numerical value ±5. The numerical values in ( ) in the table refer to the setting range for the paper.
Set each air volume to a smaller value than that of the table, when handling thin and imsy paper such as
rough paper and recycled paper. The larger the air volume, the more folding misalignment may occur.
Change the numerical value when double-feed or mis-feed occurs even though the values are set according
to the air adjustment table.
A3 / LGR A4 / LGL,LTR A5 / INV, STMT
Paper
quality
Paper ream
weight
(g/m
2
/ lb)
[Sep. Air] [Pickup Air] [Sep. Air] [Pickup Air] [Sep. Air] [Pickup Air]
Fine
quality
paper
52.3/14 35 30 (25 to 40) 35 30 40 30
64/16 40 35 40 35 45 30
81.4/22 50 45 45 40 50 35
104.7/28 60 45 50 45 50 40
127.9/34 65 50 55 45 50 40
157/40 75 50 60 50 50 45
Coated
paper
73.3/19 45 (40 to 55) 40 (35 to 50) 40 35 45 30
79.1/21 50 40 (35 to 50) 45 40 45 35
84.9/22 55 45 45 40 45 35
104.7/28 65 50 55 45 50 40
127.9/34 75 50 60 50 50 40
157/40 85 55 75 50 70 45
B4 B5 B6
Paper
quality
Paper ream
weight
(g/m
2
/ lb)
[Sep. Air] [Pickup Air] [Sep. Air] [Pickup Air] [Sep. Air] [Pickup Air]
Fine
quality
paper
52.3/14 40 35 40 30 40 30
64/16 40 35 45 35 45 30
81.4/22 45 40 50 40 50 35
104.7/28 55 45 55 45 50 40
127.9/34 60 45 60 50 60 40
157/40 65 50 60 50 65 40
Coated
paper
73.3/19 45 35 40 30 45 35
79.1/21 45 40 45 35 45 35
84.9/22 50 40 50 40 50 40
104.7/28 60 45 55 45 50 40
127.9/34 70 50 60 45 50 40
157/40 80 50 60 50 70 40
