10 | Channel setup menu 4
D-ISC 100 x xx2
109
● The maintenance signal is reset in a similar manner:
1.
In the "Maintenance functions" menu, select the "Reset main-
tenance" function.
This function should be marked as "inactive".
2.
The "Reset maintenance" function is now started by pressing
the
key. The maintenance status can be checked in the
sensor's status -> "Maintenance/Check function (C)" is inact-
ive.
10.3.4.1 [Maintenance functions]
Maintenance functions:
[
Maintenance functions]
(Further information on the maintenance functions can be found
in the relevant sensor manual.)
Maintenance functions can be stopped and started here.
[
Start zero point measurement]
● This function starts the sensor's zero point measurement.
[
Stop zero point measurement]
● This function stops the sensor's zero point measurement.
● The sensor returns to normal measuring mode.
10.3.4.2 [Simulation functions]
Simulation functions:
[
Simulation functions]
Confirm changes with
…
e.g.:
Measuring value n:
[
enter/exit fixed output mode]
n stands for the number of possible output channels.
● This function allows a simulation value to be defined for each
available output channel. This value is then output at the as-
sociated output.
● Entering a simulation value of "0" deactivates the function.
(Further information on the simulation functions can be found in
the relevant sensor manual.)
10.3.4.3 [Test functions]
Test functions
[
Test functions]
Carry out (!) with the
key.
e.g.:
[
Protection device test]
● Checks for proper functioning, e.g. of the fail-safe shutter, by
closing and opening the shutter once.
If a malfunction occurs, a fault message will be issued.
● Request is carried out immediately; no additional confirmation
prompt.
