DURAG D-ISC 100 2 Series - External Sensors] (SX1

10 | Channel setup menu 4
D-ISC 100 x xx2
117
Once this selection is made, the screen returns to the higher-
level menu (e.g.: 4.3.MX1.1) and the respective assignment is
displayed.
See also Section "Measurement display (MXo)" [}74].
A comprehensive description on configuring mixed channels can
be found in Section 15.14 Example: Configuring the mixed chan-
nel software module [}191].
10.4.1.5 [External sensors] (SX1...2)
First enable the module if necessary (10.4.1.3 Enable/disable
modules [}116]).
Additional information on the module menu (see 10.4.3.1.1 Mod-
ule name (e.g. AOx, MCx …)* [}127]) for (SX):
Assign source measured value
(4.3.SXn.2):
● [
Assign source measuring values]:
Assignment of the analogue input, to which a measured value
transmitter is connected, to a channel SX
● Assignment takes place analogous to the module MX. How-
ever, possible sources are only analogue inputs AI
Assign target measured value
(4.3.SXn.3):
● [
Assign target measuring values]:
● Assignment of the respective measured value (channel) to an
analogue output.
● Assignment takes place analogous to the sensors (see
these).
Specific parameters
(4.3.SXn.4.1 .. 4, 4 channels):
[
Specific parameter]:
Upper limit value1[
]
Change with: key…
● If the measured value exceeds this value, the status signals a
corresponding limit value infringement.
● This status signal can be assigned to a digital output if neces-
sary.
Lower limit value1 [ ]
Change with:
key…
● If the measured value falls below this value, the status signals
a corresponding limit value infringement.
● This status signal can be assigned to a digital output if neces-
sary.
Upper limit value2]
Change with:
key…
● If the measured value exceeds this value, the status signals a
corresponding limit value infringement.
● This status signal can be assigned to a digital output if neces-
sary.
Lower limit value 2 [
]
Change with: key…
● If the measured value falls below this value, the status signals
a corresponding limit value infringement.
● This status signal can be assigned to a digital output if neces-
sary.
