4 | Installation and commissioning
32
D-ISC 100 x xx2
A description of the connections can be found in Section 4.2
Connecting the network and data cables [}32].
4.2 Connecting the network and data cables
DANGER
Danger of death due to electric current!
An immediate danger of death exists in case of contact with live
parts. Damage to the insulation or individual components can
present a danger of death.
In the event of damage to the insulation, turn off the power
supply immediately and initiate repairs.
Only have work on electric systems performed by specialised
electricians.
Before opening the housing or removing the touch guard, dis-
connect the device, check that no voltage is present and se-
cure against reactivation.
Keep moisture away from live parts. This may lead to a short-
circuit.
Sensor connections
All connecting cables for connecting the sensors (including those
connected in the factory) must be ordered separately.
Additional information on the connections of the D‑ISC100 can
be found in the following Sections.
4.2.1 Instructions for planning the electrical connections to
the system
The electrical connection in the housing is established at the ter-
minal strips in accordance with the wiring diagram.
The cables for the mains and data cables should be routed
separately.
The mains cable should use H 07 RR – U 3 G 1.5 or the equi-
valent. The material of the conductors and sheath must be
appropriate to the conditions at the operating site.
To protect the mains cable, a 16A automatic circuit breaker
should be installed as near to the measuring system as pos-
sible. Label the MCB so that it can be identified as the isola-
tion switch for the device.
A D‑ISC100 can power a maximum of one sensor consisting of
one or two measuring heads. Additional sensors are powered via
a terminal box (D−TB100 or D−TB200) or by additional
D‑ISC100.
The connections between the D‑ISC100 and the sensors are
usually established by means of pre-assembled connecting
cables with plugs. No special installation work is required here.
