DURAG D-ISC 100 2 Series User Manual

13 | Technical data
D-ISC 100 x xx2
149
13.5.2 D-ISC 100 module – analogue input (analogue in)
D-ISC 100 module - analogue input (analogue in)
Analogue inputs 4x input
0…20 mA, 50 Ohm, zero point configurable
13.5.3 D-ISC 100 module – digital output (digital out)
D-ISC 100 module – digital output (digital out)
Digital outputs 8x relay output,
contact NC/NO,
max. load 60 V
/30V~/0.5 A
potential-free, assignment parametrisable
13.5.4 D-ISC 100 module – digital input (digital in)
D-ISC 100 module – digital input (digital in)
Digital inputs 8x digital input,
function via potential-free contact,
assignment parametrisable
13.5.5 D-ISC 100 software module - Modbus RTU Slave
D-ISC 100 software module - Modbus RTU
Address range 1…247
Preset address
20
(factory default)
max. number of devices
(bus loads) per bus segment
32
Table13.8: Modbus RTU address setup
13.5.6 D-ISC 100 module - Profibus DP
D-ISC 100 module - Profibus DP
Application layer DPV0
Number of cyclical input data 64 words
Number of cyclical output data 32 words
Number of modules 4 input modules
2 output modules

DURAG D-ISC 100 2 Series Specifications

General

Brand	DURAG
Model	D-ISC 100 2 Series
Category	Control Unit
Language	English
