10 | Channel setup menu 4

132

D-ISC 100 x xx2

● Overrun/Underrun: displays the assigned overrun/underrun

value (in mA) from which a channel signals an overrun/under-

run for each of the 4 individual channels; enables this value to

be edited; individually defines whether they should lead to a

system response for the individual values (value active) and

what this response should be (display error, retain value).

Setup

[

Setup]

● General: displays and edits the customer name(a user-spe-

cific name for the respective module).

● Graphic: Activates/deactivates the automatic scaling. Dis-

plays and edits the value for the start and end of the scale (Y-

axis/bar graph), which is to be used when automatic scaling is

deactivated.

Information

[

Information]

● Displays information on the D‑ISC100 device with the cur-

rently selected module and information on the versions used.

10.4.3.3 Analogue input

For assembly, also refer to 4.3.3 Analogue input [}52], and for

the module description see 3.4 Expansion modules [}25].

Functions

[

Functions]

● Service functions: enables a device restart. Settings that have

not been saved may be lost and are no longer considered

when restarting.

● Simulation functions: allow a value (simulation value) to be

assigned and the use of the assigned value (simulation re-

quest, activate simulation) for each of the 4 channels.

Common parameter

[

Common parameter]

● Common parameter: displays data such as the manufac-

turer's name, device name, device type, serial number and

firmware version under device information (list).

Specific parameter

[

Specific parameter]

● Overrun/Underrun: displays the assigned overrun/underrun

value (in mA) from which a channel signals an overrun/under-

run, for each of the 4 individual channels and also enables

these values to be edited.
