Performance description
Operating manual 171/173 Version 01.0 - 01/2016 9
2.4 Additional equipment
Using a flexible system of additional equipment, the machine can be equipped optimally
and cost-effectively to suit the relevant application.
= Standard equipment
= Optional extension
Max. number of stitches [per min.] 6,600 6,000 6,000 6,000 5,500 6,000
Number of stitches on delivery [per min.] 6,600 5,800 5,800 5,800 5,500 5,500
Number of stitches, use of hemming
system [per
min.]
5,500 - -
Max. number of stitches as twin-needle
machine
(depending on E-No.) [per min.]
5,500 - 5,500 - 5,500 -
Sewing foot stroke during sewing [mm] 4 4
Sewing foot stroke during lifting [mm] 10 9 5
Needle stroke [mm] 32 30 32 30 30
Operating pressure [bar] - 6 - 6 - -
Air consumption [NL] - 0.1 - 0.1 - -
Length/width/height [mm] 500/175/380
Weight of the upper section [kg] 37 38 39 40 39 39
Rated voltage [V/Hz] 190 - 240 V/50 - 60 Hz
Rated voltage on delivery 1x230 V/50 - 60 Hz
Rated power [kVA]
0.5
Features
Model 171 Model 173
171-
131610
171-
141621
173-
141610
173-
141621
550-2-2
550-15-5
