Operation
Operating manual 171/173 Version 01.0 - 01/2016 35
5.7.2 Adjusting the stitch condensing
For machines with pushbuttons on the machine arm
( 5.12 Keypad on the machine arm, pg. 42) it is possible
to switch over to stitch condensing while sewing. The stitch length
for stitch condensing can be adjusted by turning the adjusting
wheel (2) continuously between 1 and 4 mm. The adjusting
ma
rk (1) on the left of the wheel indicates the stitch length selected.
Important: The
stitch length for stitch condensing must not be
larger than the normal stitch length.
Fig. 19: Adjusting the stitch condensing
Adjusting the stitch length for stitch condensing:
1. Turn the adjusting wheel (2):
• T
o increase the stitch length:
Turn the adjusting wheel counterclockwise.
• T
o reduce the stitch length:
Turn the adjusting wheel clockwise.
Machine damage possible if the adjusting wheels
are turned using excessive force.
The machine is designed in such a way that it is not
possible to select a larger stitch length on the lower
adjusting wheel than on the upper adjusting wheel.
Do not use excessive force in attempting to select
a larger stitch length on the lower adjusting wheel.
ATTENTION
①②
(1) - Adjusting mark (2) - Stitch length adjusting wheel
