Operation
Operating manual 171/173 Version 01.0 - 01/2016 43
5.13 Operating the controller
The machine is operated using the DAC eco or DAC classic
controller. Operation of the controller is described in its own
o
perating manual.
The operating manual for the DAC eco or DAC classic is provided
in
the accessory pack delivered with the controller.
The operating manual is also available in the download area
at www.duerkopp-adler.com
5.14 Sewing
The foot pedal starts and controls the sewing process.
Fig. 27: Sewing with the foot pedal
Risk of injury from the needle tip on unintentional
start of sewing.
Take care not to accidentally press the foot pedal
when your fingers are in the needle tip area.
WARNING
(1) - Pedal position +1:
Sewing active
(2) - Pedal position 0:
Rest position
(3) - Pedal position -1:
Raises the sewing foot
(4) - Pedal position -2:
Sews an end strip
and cuts thread
①
②
④
③
