Operation
Operating manual 171/173 Version 01.0 - 01/2016 41
5.11
Locking the sewing foot in the upper position
The pushbutton on the machine head can be used to hold
the lifted sewing foot in the upper position.
Fig. 25: Locking the sewing foot in the upper position
Locking the sewing foot in the upper position
1. Lift the sewing foot with the knee lever or the pedal.
( 5.1
0 Lifting the sewing foot, pg. 40)
2. Press the locking pushbutton (1).
3. Release the knee lever or pedal.
The sewing foot is locked in
the upper position.
Canceling the lock
1. Push the knee lever to the right again or press the pedal
half-way back.
The sewing foot is lowered. The lock is canceled.
(1) - Locking pushbutton
Risk of crushing when lowering the sewing foot.
Do not put your hands underneath the sewing foot
when the lock is being canceled.
CAUTION
