Set-up
Operating manual 171/173 Version 01.0 - 01/2016 53
6Set-up
6.1 Checking the scope of delivery
Important: The scope of delivery depends on your specific order.
1. Prior to set-up, check that all parts are present.
Fig. 32: Example of the scope of delivery
Risk of injury.
The machine may only be set up by trained specialists.
Wear safety gloves and safety shoes when unpack-
ing and setting up.
WARNING
(1) - Machine upper section
(2) - Table plate
(3) - Drawer
(4) - Frame
(5) - Pedal
(6) - Setpoint device
(7) - Maintenance unit
(8) - Controller
(9) - Reel stand
①
⑥
⑨
⑦
⑧
②
③
④
⑤
