DURKOPP ADLER 756 A

To Next Page

To Previous Page

Programming

Service Instructions 755 A/756 A - 00.0 - 02/2019 295

2. Press the desired button.

 The user interface for setting the desired item is displayed.

Correction light barrier  p. 308

Marking lamps 1-16  p. 310

Sewing head parameters  p. 314

Middle knife parameters  p. 318

Corner knife  p. 320

Automatic tape feeder (optional,  p. 329)

Transport clamp  p. 330

Process of transport clamp  p. 333

Program loading process  p. 337

Stacker/smoother/blow-off/roll-off  p. 345

Reset seam program to default values

Zipper cutter On/Off (optional)

Symbols Meaning
