MK-6 Operation Manual 37
Basic Operations
Main Screen
Main Screen The Main Screen is accessed by pressing the Main button located directly
under the data entry control. From this screen you can examine or change
the Preset, Volume, Pan Position and Preset Location for each of the 16
MIDI channels.
MIDI Channel
Selection
To Change the MIDI Channel:
1. Press the Main button to display the Main screen.
2. Press the Channel inc/dec buttons located to the left of the liquid
crystal display to select channels 01 through 16. The preset, volume
and pan settings for each channel will be displayed as you scroll
through the channels.
The channel number shown in the main screen is the “Basic MIDI Channel”
when in Omni or Poly modes.
Preset Selection To Change the Preset:
1. Press the Main button to display the Main screen.
2. Press either cursor key until the cursor is underneath the preset
number. (The cursor is a little flashing line underneath one of the
parameters in the display.) As you rotate the data entry control, the
preset number and name changes.
3. The displayed preset is assigned to the displayed MIDI channel. Presets
are arranged into banks of 128, as shown in the diagram at left.
Using the screen above as an example, the superscripted number 2 in the
second line of the display identifies the current bank number.
• Select banks independently of the of the preset number by locating the
cursor on the Bank field and turning the data entry control.
C01 V127 P01
R
A:off User
079
3
kit: Hide & Seek
Bank Contents
128 RAM Presets
128 RAM Presets
128 RAM Presets
128 RAM Presets
128 ROM Presets
128 ROM Presets
128 ROM Presets
Depending on
ROM sets installed
0
1
2
3
0
1
2
??
USERROM 1
C01 V127 P01
R
A:off User
Number
Preset
Bank Number
079
3
bts: Logic
