24 E-MU Systems
Instant Gratification
Exploring the Master Arpeggiator
Exploring the Master
Arpeggiator
MK-6’s multi-channel Pattern Generator/Arpeggiator is one of the greatest
features ever put in a synth. Let’s explore the Master Arpeggiator.
To Arpeggiate a Single Preset:
1. Select a preset. Note that the factory presets all have prefixes which
describe the type of sound. For this investigation it might be best to
choose a preset with the prefix “arp,” for arpeggiator. These presets are
optimized for use with the arpeggiator.
2. Set the Arp parameter in the main preset selection screen to “M” for
Master Arpeggiator.
3. Press the Arp/Beats button in the Edit section of the front panel to
access the master Arpeggiator menu, then use the data entry control to
scroll to the screen shown below.
4. Make sure the arpeggiator Status is “on.” Play the keyboard to start
arpeggiating.
5. Press either cursor key repeatedly to move the cursor below the Status
field.
6. Turn the data entry control clockwise one click. The Mode screen
appears.
7. Use the cursor keys to move the cursor to the Mode field (up, down, up/
down, forw asgn, backw asgn, forw/backw, random, pattern). Try out
the different modes as you play the keyboard.
8. Move the cursor back to the lower left position and explore the other
parameters. The Note Value parameter changes the rate of the arpeggios.
By the way, note value is a divisor based on the Master Tempo. Try
changing the tempo, but come right back.
C01 V127 P01R A:M MROM1
000
0
arp: Guitartar
MASTER ARPEGGIATOR
S
tatus on
MASTER ARPEGGIATOR
Mode u
p
To Next Page
