Eaton 93E MK2 - Figure 4-4. Power Terminal Locations 10;15;20;30 Kva; Figure 4-5. Power Terminal Locations 40 Kva

Neutral (N)
Phase A (L1)
Phase B (L2)
Phase C (L3)
Phase C (L3)
Phase B (L2)
Phase A (L1)
Phase C (L3)
Phase B (L2)
Phase A (L1)
Rear View
93E MK2-10 / 93E MK2-15 / 93E MK2-20 / 93E MK2-30
Figure 4-4. Power Terminal Locations 10/15/20/30 kV A
Neutral (N)
Phase A (L1)
Phase B (L2)
Phase C (L3)
Phase C (L3)
Phase B (L2)
Phase A (L1)
Phase C (L3)
Phase B (L2)
Phase A (L1)
Rear View
93E MK2-40
Figure 4-5. Power Terminal Locations 40 kV A
UPS Bypass Input
Ground Terminal
UPS Mains Input UPS Output
UPS Bypass Input
UPS Mains Input UPS Output
Ground Terminal
27
Eaton 93E MK2 UPS (10-40kVA, 380/400/415V) Installation and Operation
