4.
Remove
the small parts from the
knockout
in the right side
plate.
5. Route and install RJ-45 Controller Area
Network
(CAN)
cables between
the UPS
cabinets.
See Figure 4-
6,
and
Figure 4-10 for wiring inf
ormation.
6. Route and install pull chain wiring
(17-20AWG
T
wisted
Wires
)
between
the UPS
cabinets
and
cabinet
MOBs. See
Figure 4-6 and Figure 4-10 for wiring inf
ormation.
7. If wiring Mini-Slot
connections, proceed
to
paragraph 4.5.3;
4.5.3
Installing Mini-Slot Interface
Connections
AN
drop for
connection
to UPS
communications
card is to be
supplied
b
y
customer
.
For installation and
setup
of an Mini-Slot card,
contact
an Eaton
service representative
(see
paragraph
1
.8)
To install
wiring:
1. If not already installed, install the
LAN
drop.
2. Route and install the
LAN
and other
cables
to the
appropriate
Mini-Slot
cards.
See Figure 4-6 and Figure
4-7
for
Mini-Slot
communication
bay
locations.
3. Refer to the manual
supplied
with the Mini-Slot card for
operator
instr
uctions.
Eaton 93E MK2 UPS (10-40kVA, 380/400/415V) Installation and Operation
