Eaton 93E MK2 - Figure 4-14. Normally-Open REPO Switch Wiring; Table 4-4. Normally-Open REPO Wire Terminations

5. If using a normally-closed REPO switch, connect a jumper wire between pins 3 and 4 on the REPO
terminal
bloc k.
6. If installing multiple REPO switches, wire additional switches in parallel with the first REPO .
7. If required, install wiring from the REPO switch to the trip circuitry of the upstream protective devices. A
second contact block is provided on the REPO switch for this function . The REPO switch wiring must be in
accordance with local regulations.
T able 4-4. n or ma ll y -O pe n REPO Wire Termination
From REPO Station(s)
Switch Contact Block
(Either Block)
To REPO Terminal Block
on Back of UPS Cabinet Wire Size T ightening T orque
3,4 NO See Figure 4-12 for wiring T wisted Wires (2)
14-22AWG
(0.5
- 2.0 mm
2
)
7 lb in
(0.8 Nm)
1
2
REPO TB
3
REPRO
Switch
(No)
4
3
T wisted
Wires
4
Figure 4-14. Normally-Open REPO Switch Wiring
35
Eaton 93E MK2 UPS (10-40kVA, 380/400/415V) Installation and Operation
