Eaton 93E MK2 - Ups Operating Instructions; UPS Controls and Indicators; Figure 6-1. UPS Controls and Indicators

Chapter 6 UPS Operating Instructions
This section describes how to operate the UPS .
NOTE 1
NOTE 2
Before
starting the UPS, ensure all installation tasks are complete and a preliminar y
startup has been performed by authorized service personnel. The preliminar y
startup verifies all electrical interconnections to ensure the installation w as
successful and the system operates properly .
Read this
section of the manual and have thorough knowledge of UPS operation before
attempting
to operate any of the controls.
6.1 UPS Controls and Indicators
The controls and indicators identified and described in this section are used to control and
monitor
UPS
operation. Figure 6-1 shows the controls and indicators and Figure 6-2 shows the UPS
switc hes.
Control P anel
Door
Latc h
Figure 6-1. UPS Controls and Indicators
6-1
Eaton 93E MK2 UPS (10-40kVA, 380/400/415V) Installation and Operation
