Eaton 93E MK2 - Figure 4-15. Normally-Closed REPO Switch Wiring; Table 4-5. Normally-Closed REPO Wire Terminations

T able 4-5. N or ma l ly -C lo s e d REPO Wire Terminations
From REPO Station(s)
Switch Contact Block
(Either Block)
To REPO Terminal Block
on Back of UPS Cabinet Wire Size T ightening T orque
1,2 NC
See Figure
4-15 for
wiring T wisted Wires (2)
14-22AWG
3,4 NC (0.5 -2.0mm
2
)
7 lb in
(0.8 Nm)
REPRO
1
Switch
(NC)
2
Figure 4-15. Normally-Closed REPO Switch Wiring
T wisted
Wires
1
2
REPO TB
3
4
36
Eaton 93E MK2 UPS (10-40kVA, 380/400/415V) Installation and Operation
