Eaton 93E MK2 - Inspecting and Unpacking the UPS Cabinets

UPS Installation Plan and Unpacking
3.3 Inspecting and Unpacking the UPS Cabinets
The cabinet is shipped bolted to a wooden pallet and protected with an outer wood cont ainer .
W ARNING
The UPS cabinet is heavy (see Table 3-1). If unpacking and unloading instructions are not closely
followed, the cabinet may tip and cause serious injury .
1. Carefully
inspect the outer packaging for evidence of damage during transit.
CAUTION
Do not install a damaged cabinet. Report any damage to the carrier and contact an
Eaton
service representative immediately .
NOTE
For the follow
ing
step, verify that the forklift or pallet jack is rated to handle the weight of
the cabinet (see Table 3-1 for cabinet w eight).
2. Use a forklift or pallet jack to move the packaged cabinet to the installation site, or as
close as
possible, before unpacking. If possible, move the cabinets using the pallet.
Insert the forklift or pallet jack f
orks between the supports on the bottom of the
pallet (see Figure 3-6
through Figure 3-10 for the UPS cabinet centre of gravity
measurements).
CAUTION
Do not tilt the UPS
cabinets more than 10° from vertical or the cabinets may tip o v er .
3. Set the pallet on a firm, level
surface, allowing a minimum clearance of 3m (10 ft) on
each side f
or removing the cabinet from the pallet.
4.
Remove the inner protective packaging. Retain the ramp brac k ets.
5. Recycle the remainder of the outer shipping container and the inner protective
packaging
in a responsible manner .
6.
Inspect the contents for any evidence of physical damage, and compare each item
with the
Bill of Lading .
If
damage has occurred or shortages are evident, contact an Eaton service representative
immediately
to determine the extent of the damage and its impact on further inst allation.
