MGR10 A/B/C - Revision : I (for 7.0 software revision) 26
IMPORTANT NOTICES ON THE  /km and km MODES :
1) The
 /km and km functions are not operating in RS232 or IEEE488 modes but are operating
in the PLC mode .
2) The temperature compensation function stays operating .
3) The comparison function with high and low limits , the analog output and the data storage are
not following the
 /km and km modes and continue to work on the real Rx value in Ohms .
4) The ZERO function is not working in the
 /km and km modes
5) Only the SLOW mode allows operating
 /km and km functions .
Trig Mode :
 Press on [Trig Mode ] to select the measurement trigger modes.
 Press on [Cont] to activate the continuous measurement mode
 Press on [Sing ] to activate single measurement mode. This mode performs a measurement
and memorizes the value on the display .To trigger a new measurement , press on the
[MES] key .
 Press on [OK] to go back to the previous page
 Press on [QUIT ] to escape the menu .
Read rate :
 Press on [Read rate ] to select the measurement speed
 Press on [Slow] to activate a display with large characters and with a rate of 2 measurements
per second which gives the best resolution and accuracy .
 Press on [Med] to activate a display with large characters and with a rate of 4 measurements per
second which gives the best resolution and accuracy .
 Or press on [Fast ] to perform measurement with a rate of 50 per second . This mode is
mainly advised when operating the unit from a remote interface . The measured values are
displayed in small characters and the accuracy is reduced .
 Press on [OK] to go back to the previous page
 Press on [QUIT ] to escape the menu .
Filt :
 Press on [Filt] to select the digital filter, this feature should be used when the sample to be
measured is unstable and the measured value displayed is constantly changing. The filter is a
rolling average of n measurements, where n may be set between 1 and 32.
 Press on [No. Rdgs] to enter the number of measurements : No of readings : 10 .
 Press on [Chg] to change the value and enter the value with the numeric keypad .
 Press on [OK] to enter the new value .This value will be displayed in the right upper
corner of the LCD screen if the filter is activated . Filt : n
 Or press on [OK] to keep the previous value
 Press on [On] to activate the filter mode.
