MGR10 A/B/C - Revision : I (for 7.0 software revision) 7
The MGR10 is a true four wire measuring instrument eliminating the need to compensate for lead
resistance. The measured value is displayed in large characters with decimal point and units k, ,
or m. For maximum accuracy the measuring current may be automatically reversed and the
average of measurement displayed. For measurements on unstable samples, a rolling average filter
is available.
Resistance measurement accuracy is typically 0.03% (1 year specification) and the value may be
displayed with or without temperature compensation, the final accuracy depends upon the current
selected.
The front panel measurement connections are made via 4mm sockets located on the front panel
(rear panel connection is an option). The connection to a Pt100 temperature sensor is made with a
standard DIN connector.
Available models :
Model Description
MGR10 Basic unit
MGR10A Basic unit with batteries power
MGR10B Basic unit for NFC93050 contact resistance measurement
MGR10C Basic unit for pyrotechnic measurement
