Parameters
04/10 MN04020001Z-EN
122
PNU ID Access right
RUN
Value Description Factory setting
(P1.3)
P13.1 1453 - LOG function, Selection input A 0
Value range for signal A.
0 Deactivated
1 READY, the frequency inverter is ready for operation.
2 RUN, the inverter of the frequency inverter is enabled (FWD, REV).
3 FAULT, error message
Error detected (= STOP).
4 Error message inverted (no error message).
5 ALARM, warning message
(a section “Protective functions (P8)”)
6 REV (Reverse run), anticlockwise rotating field active
7 Output frequency = frequency setpoint
8 Motor controller active
9 Zero frequency
Output frequency = 0 (Hz)
10 Frequency monitoring 1
For the frequency ranges set at P5.4 and P5.5.
11 Frequency monitoring 2
For the frequency ranges set at P5.6 and P5.7.
12 PID monitoring
For the deviation set at P9.17
13 Overtemperature message
14 Overcurrent control active.
15 Overvoltage control active.
16 PLC Sequence control active.
17 PLC Sequence control, single step completed.
18 PLC Sequence control, program cycle completed.
19 PLC Sequence control, pause.
20 Counter, value 1 reached.
The counter value is f the trigger value set at P3.21 and can be
reset by activating P3.24.
21 Counter, value 2 reached.
The counter value is f the trigger value set at P3.22 and can be
reset by activating P3.24.
22 RUN message active
23 Setpoint error (live-zero).
Message, AL 50 if the value of AI1 and/or AI2 goes below the
4 mA or 2 V setpoint value (live zero) (P2.1 = 1, P2.5 = 1).
24 LOG function fulfilled.
Message if the logical operation of P13.3 is fulfilled (LOG = 1).
25 PID controller, actual value monitoring.
Message if the actual value is within the hysteresis set at P9.15
and P9.16.
