Page #85 background imageLoading...
Page #85 background image
04/10 MN04020001Z-EN
Parameter menu (PAR)
81
P3.17 1404 / Block parameters 0
Assignment of control signal terminal as per P3.2.
Blocks access to all parameters.
Note: The resetting of all parameters to the default settings via
the STOP button (held down 5 s) remains active.
P3.18 1405 / Motor potentiometer, increase value.
Acceleration time a section “P6.5” (acc1).
0
Assignment of control signal terminal as per P3.2.
P3.19 1406 / Motor potentiometer, reduce value.
Deceleration time a section “P6.6” (dec1).
0
Assignment of control signal terminal as per P3.2.
P3.20 1407 / Motor potentiometer, set value to zero. 0
Assignment of control signal terminal as per P3.2.
P3.21 1408 / PLC Sequence control, program start. 0
Assignment of control signal terminal as per P3.2.
P3.22 1409 / PLC Sequence control, program pause. 0
Assignment of control signal terminal as per P3.2.
P3.23 1410 / Counter, input signal. 0
Assignment of control signal terminal as per P3.2.
Counts the activation of the selected digital input (DI1 - DI6).
P3.24 1411 / Counter, reset 0
Assignment of control signal terminal as per P3.2.
Resets the outputs P5.1 = 20, P5.1 = 21 and display value M1.21
to zero.
P3.25 1412 / Change control level. 0
Assignment of control signal terminal as per P3.2.
Move between the control levels set at P6.1 and P6.17 (LOC-REM
function).
P3.26 1413 / Change setpoint source (I/0). 0
Assignment of control signal terminal as per P3.2.
Switch between the setpoint sources AI1 and AI2 set at P6.2 and
P6.18.
P3.27 1414 / Activate second parameter set (2PS). 0
Assignment of control signal terminal as per P3.2.
The values set at the parameter group P14 are activated.
P3.28 1415 / Field bus, Remote Input 0
Assignment of control signal terminal as per P3.2.
The assigned digital input is written directly to the general status
word (ID 2102, bit 11).
P3.29 1416 / Meter, output signal 1 0
Trigger value for P5.1 = 20
P3.30 1417 / Meter, output signal 2 0
Trigger value for P5.1 = 21
PNU ID Access right
RUN
Value Description Factory setting
(P1.3)
