Ecotech Serinus 40 User Manual

Serinus 40 User Manual 2.2
Page 90
5.6 Pressure Calibration
The pressure calibration involves a two point calibration. One point is under vacuum and another
point is at ambient pressure. To perform a pressure calibration the following steps must be
completed.
Note: The vacuum calibration must be performed first when performing a full pressure calibration.
Vacuum Point Calibration
1. Enter Calibration menu  Pressure Calibration and Open
Figure 40 – Vacuum calibration, ozone generator offline warning
Note: This action will disable the ozone generator and place the valve sequence on hold.
2. Select Vacuum Set pt.  OK
Figure 41 – Vacuum calibration, on-screen instructions
3. Open the instrument.
4. Remove the tubing connecting the dryer to the exhaust line and block the exhaust line T-piece
(see Figure 42 – Blocking exhaust T-piece).
