B8J200880_E - Accessories
Page 127
Table 47 Auxiliary extension cable
Item
Item Number
nEXT auxiliary extension cable
B8G200836
14.12 Auxiliary 'Y' cable adaptor
Enables either a TAV vent valve and a cooling fan or two cooling fans or 2 TAV vent valves
to be operated at the same time. The two sockets of the Y-cable are wired in parallel so
either connector can be used in exactly the same way as the auxiliary connector on the
pump itself.
Table 48 Auxiliary extension cable
Item
Item Number
nEXT auxiliary ‘Y’ cable adaptor
B8G200837
14.13 EPS 800 power supply
The EPS 800 is a power supply unit for powering the nEXT turbomolecular pumps.
The EPS 800 can be fitted to the pump or utilized as a benchtop unit.
Table 49 EPS 800 power supply
Item
Item Number
EPS 800
B8J200819
Mains cable, 3 m CA-3-LD EU
B8J200829
Mains cable, 3 m CA-3-LD US
B8J200830
Mains cable, 3 m CA-3-LD UK
B8J200831
Extension cable nEXT, 3 m
(between pump and power supply)
B8J200824
