B8J200880_E - Technical data
Page 32
Figure 7 Dimensional drawing for nEXT1230H
Ø A
X
All measurements indicated are shown in mm
1. PURGE G 1/8"
2. VENT G 1/8"
3. Water cooling, quick coupling for 8 mm hose
4. 48 V d.c. power supply cable, 0.6 m long including plug
5. Control interface cable, 0.95 m long including plug
Table 6 Dimensions in mm
DN
H
A
nEXT1230H
200 CF
320.1
254
nEXT1230H
200 ISO-K
290.1
240
nEXT1230H
200 ISO-F
292.6
285
4x
M8-14
6
1
2
M6
3
55
X
35
DN 40 KF
4x M5-8
4
5
204
244
H
244
204
134.6
53
45
134.5
21
50
53
BC-0033-B
