B8J200880_E - Technical data
Page 28
nEXT
1230H
Recommended forevacuum pumps
XDS35i or E2M28
Noise level
with convection cooling
with radial air cooler
dB(A)
< 44
< 55
Maximum bake-out temperature of the
CF version, water cooled
°C
100
–
–
Purge gas flow
mbar · I · s
-1
sccm
0.4
24
Purge gas connection
G 1/8"
Venting connection
G 1/8"
Magnetic field resistance
▪ for an axial magnetic field
▪ for an radial magnetic field
mT
160
7.8
Magnetic stray field at
▪ in axial direction
▪ in radial direction
mGauss
400
100
* Depending on the ambient temperature, the gas throughput and the type of gas,
forced air cooling or water cooling may be necessary.
§ Please contact the supplier to discuss your specific system details and the necessary
achievements for pumping speed, compression ratio and ultimate pressure.
† For some pump classes, different pumping speeds are specified for pumps with ISO
and CF flanges, as differences in flange geometry here lead to a difference in
performance of > 5%.
‡ The compression ration of a TMP describes the performance of the TMP design for
the compression of a gas type at special conditions. The compression data were
measured only using the CF flange variants.
