Edwards STP-iX455

STP-iX455/iXL455 Series Instruction Manual
15-2
Specification
Table 15.1 Specifications for the STP Pump (2/2)
Item Specifications
Input voltage
VDC
48
Input current
A
Max.
5
Motor driving system
Th
ree phase
DC
brushless motor driver
Output
voltage
under
normal operation
Hz 750 to 917
Panel indication lamp
POWER
(green LED)
ROTATION (green/orange LED)
FAILURE
(red/orange LED)
Input/Output terminal
X1 DC POWER
(7 pin circular connector)
X2 REMOTE
(25 pin Dsub connector)
X3 COM1(RS232/485)
(9 pin Dsub connector)
X5 STP
-
Link (COM2)
(8 pin Mini
-
DIN connector)
X6 VENT VALVE
(4 pin circular connector)
X7 FAN
(2 pin r
ectangular
c
onnector
)
