STP-iX455/iXL455 Series Instruction Manual
1-2
Installation
1.3 Labels
The following labels are affixed to the STP pump.
Read the contents of the labels before operation.
For the positions of the labels, see Figure 15.3, "Label Affixing Position for the STP
Pump".
1) STP Pump Installation Warning Label
This label describes installation of the STP pump.
Install the STP pump according to the precautions of Section 4, "Installation of the
STP Pump".
2) Rotational Direction Instruction Label
This label describes the rotational direction of the STP pump.
The STP pump rotates in this direction.
3) Hot Surface Warning Label
This label instructs operators so as not to touch the hot surface of the STP pump.
The control unit will become high temperature while the STP pump is in operation.
The use of the baking heater (optional accessory) may lead to a considerable rise in
temperatures outside the STP pump. This label warns operators so as not to burn
hands.
