Edwards STP-iX455

STP-iX455/iXL455 Series Instruction Manual
9-41
Operation
9.4.15 SetOptionFunc
Function:
Changes the setting value of the remote operation mode, vent valve, warning
function, and serial communication time out.
◇ There is an endurance limit of setting changes (no more than 24 times per day for
about ten years). If this limit is exceeded, it not only may become impossible to
change the setting but can also cause pump failure. Do not make setting changes
in excess of this endurance limit.
Transmission Frame:
PC→SIM
Stx 0 0 1 Sp = Parameter 1 to 13 Etx LRC
SIM→PC
Ack
PC→SIM
Ack
SIM→PC
Stx 0 0 1 # Etx LRC
*1:
The HEX code of ASCII character ' = ' is "3D".
Parameter Item Data format Remarks
1
Remote operation mode
setting
8-bits hexadecimal
coded ASCII
Default 01
hex
(I/O REMOTE)
2 [System reservation]
16-bits hexadecimal
coded ASCII
*1
3
Vent valve
Enable/Disable setting
8-bits hexadecimal
coded ASCII
Default FF
hex
(DISABLE)
4
Vent valve starting speed
setting (Unit：%)
8-bits hexadecimal
coded ASCII
Default 32
hex
(50 %)
5
Vent valve running time
setting (Unit：sec.)
16-bits hexadecimal
coded ASCII
Default 003C
hex
(60 sec.)
6 [System reservation]
16-bits hexadecimal
coded ASCII
*1
7
Damage Limit Warning
Enable/Disable setting
8-bits hexadecimal
coded ASCII
Default 00
hex
(ENABLE)
8
Pump Runtime Over Warning
Enable/Disable setting
8-bits hexadecimal
coded ASCII
Default FF
hex
(DISABLE)
9
Pump Runtime Over Warning
Hours setting (x 100 hours)
32-bits hexadecimal
coded ASCII
Default
00000000
hex
10
Imbalance Warning
Enable/Disable setting
8-bits hexadecimal
coded ASCII
Default 00
hex
(ENABLE)
11 [System reservation]
40-bits hexadecimal
coded ASCII
*1
12
Serial communication
time out setting (Unit: sec.)
16-bits hexadecimal
coded ASCII
Default 003C
hex
(60 sec.)
13 [System reservation]
88-bits hexadecimal
coded ASCII
*1
*1:
Send the parameter value F
hex
.
Refer to Table 9.12, "Parameter Setting Value" for each parameter setting value.
*1
