STP-iX455/
iXL455 Serie
s Instruction Manual
9-27
Operation
Table 9.10
P
ump Operation Mode
Pump operation mode
Value
Levitation
1
No Levitation
2
Acceleration
3
Normal
4
Deceleration (Brake)
5
Autotest
6
[System reservation
]
7
[System reservation
]
8
[System reservation
]
9
[System reservation
]
10
[System reservation
]
11
Example:
Pump operation
mode
: 01
hex
= 1 = Levitation
The number of
error
: 02
hex
= 2 errors
Error 1
: 0D
hex
= 13 = Disturbance Xh
Error 2
: 0F
hex
= 15 = Disturbance Xb
Error 3 to 79
: 00
hex
= No error de
tected
Parameter
1
2
3
4
5
6
7
8
9
10
ASCII
0
1
0
2
0
D
0
F
0
0
0
0
0
0
0
0
0
0
0
0
HEX
30
31
30
32
30
44
30
46
30
30
30
30
30
30
30
30
30
30
30
30
Parameter
11
12
13
68
69
70
ASCII
0
0
0
0
0
0
[Om
itted]
0
0
0
0
0
0
HEX
30
30
30
30
30
30
30
30
30
30
30
30
Parameter
71
72
73
74
75
76
77
78
79
80
ASCII
0
0
0
0
0
0
0
0
0
0
0
0
0
0
0
0
0
0
0
0
HEX
30
30
30
30
30
30
30
30
30
30
30
30
30
30
30
30
30
30
30
30
Parameter
81
ASCII
0
0
HEX
30
30
92
94
