STP-iX455/iXL455 Series Instruction Manual
3-1
Installation
3 Unpacking
3.1 Unpacking the STP Pump
Check the following before unpacking the STP pump.
Check the package for bruises, breakage, wetness, and other.
If there is any abnormality/error or it is judged necessary to return the product,
contact Edwards or the distributor.
Check the contents of the package.
See Section 3.2, "Accessories".
◇ Be careful not to scratch the flange of the STP pump.
Before installing the STP pump, check whether or not there are scratches on the
surface.
◇ It is recommended to keep the packaging materials, such as the corrugated
fiberboard container and cushioning material for possible reuse.
3.2 Accessories
Table 3.1 Accessories
Item
Q
’
ty
Remarks
Instruction Manual
1
This manual
Inlet port cover
1
Outlet port cover
1
Connector for "X1 DC POWER" 1
Model: NJC–207–PF
(Nanaboshi Electric Mfg.Co,Ltd.)
Cable bushing Model: NJC–20–CB
(Nanaboshi Electric Mfg.Co,Ltd.)
Connector for "X2 REMOTE"
1
D
-
sub25 pin
Table 3.2 Accessories for Corrosion Resistant Pump
The accessories listed below are supplied to the corrosion resistant pump (type C or other
models) in addition to the accessories in Table 3.1.
Item
Q’ty
Remarks
Blank flange for purge port
1
KF
*1
10
Clamping ring for purge port
1
KF
*1
10
O
-
ring washer for purge port
1
KF
*1
10
*1
: ISO2861–1 (JIS–B–8365）
