EG4 6000XP - Page 6

2
STANDARDS AND CERTIFICATIONS
UL1741
FCC PART 15, CLASS B
INGRESS PROTECTION RATING
IP20
*Idle consumption value tested with constant 300VDC PV source
**115A @ 48VDC (AC), 125A @48VDC (PV)
***See EG4 Warranty Registration for terms and conditions
HIGH DC RECOVERY VOLTAGE 57.4VDC(Lithium) | 58VDC(Lead-Acid)
LOW DC WARNING VOLTAGE (LEAD-ACID)
LOAD<20% 44.0 VDC (Configurable)
20%≤LOAD<50% Warning Voltage @Load <20% - 1.2V
LOAD≥50% Warning Voltage @Load <20% - 3.6V
LOW DC WARNING VOLTAGE RETURN (LEAD-ACID) Low DC Warning Voltage @Dierent Load +2V
LOW DC CUT-OFF VOLTAGE (LEAD-ACID)
LOAD<20% 42.0VDC (Configurable)
20%≤LOAD<50% Cut-O Voltage @Load <20% - 1.2V
LOAD≥50% Cut-O Voltage @load <20% - 3.6V
LOW DC CUT-OFF RETURN VOLTAGE (LEAD-ACID)
CUT-OFF VOLTAGE
@LOAD <20% ≥45V
CUT-OFF VOLTAGE
@LOAD <20% <45V
Low DC Cut-O Voltage @load <20% +3V
48V
LOW DC WARNING SOC
20% SOC (Configurable)
LOW DC WARNING RETURN SOC Low DC Warning SOC +10%
LOW DC CUT-OFF SOC
15% SOC (Grid ON) (Configurable)
15% SOC (Grid OFF) (Configurable)
LOW DC CUT-OFF RETURN SOC Low DC Cut-O SOC +10%
CHARGE CUT-OFF V O LTAG E 58.4VDC
GENERAL DATA
MAX. UNITS IN PARALLEL
16
INTEGRATED DISCONNECT
Yes
DC SWITCH RATING FOR EACH MPPT
Yes
DIMENSIONS
18×25.5×5.25 in (457×648×132mm)
WEIGHT
52.9 lbs. (24kg)
COOLING CONCEPT
Fan
TOPOLOGY
TL (Transformerless)
RELATIVE HUMIDITY
5-95%
ALTITUDE
<6561ft (2000m)
OPERATING TEMPERATURE RANGE
32 – 113°F (0 – 45°C)
STORAGE TEMPERATURE RANGE
5 – 140°F (-15 – 60°C)
NOISE EMISSION (TYPICAL)
<58 dB
DISPLAY
LCD + LED
COMMUNICATION INTERFACE
RS485/Wi-Fi/CAN
STANDARD WARRANTY 5-year standard warranty***
PV REVERSE POLARITY PROTECTION, POLE SENSITIVE
LEAKAGE CURRENT MONITORING UNIT, SURGE
PROTECTION DEVICE, OUTPUT OVER-V OLTA G E
PROTECTION, OUTPUT OVER-VOLTAGE PROTECTION
VARISTOR
Yes
SCAN FOR LATEST
SPEC SHEET
