14.2 WARNING DEFINITIONS AND TROUBLESHOOTING
CODE DESCRIPTION TROUBLESHOOTING
W000 Battery communication failure
Check the battery settings to ensure they are set
for the specific battery type. Check the battery
communications cable for proper
pinning/installation.
W001 AFCI Com failure
Restart Inverter. If the error persists, contact the
distributor
W002 AFCI High
Check each PV string for correct open circuit
voltage and short circuit current. If the PV strings
are in good condition, please clear the fault on
inverter LCD
W003 Meter communication failure
Check communications cable. Contact the
distributor if error persists
W004 Battery BMS fault
Inverter is receiving incorrect information from
battery’s BMS. Restart batteries and ensure the
communication cables are installed correctly. If
error persists, please contact the distributor
W006 RSD Active Check if the RSD switch is pressed
W008 Firmware mismatch
Contact the distributor/installer for Firmware
update
W009 Fan Stuck Check if the fan is operable
W012 Bat on Mos
Restart the inverter. If error persists, please
contact the distributor
W013 Over temperature
The temperature of inverter is nearing the high
limit
W015 BatReverse
Double check battery connections to inverter. If
error persists, contact the distributor
W018 AC Frequency out of range
Check AC frequency to ensure it is in the operable
range
W019 AC inconsistent in parallel system
Ensure the AC input is from a common source and
installed to each inverter in parallel. If error
persists, contact the distributor
W020 PV Isolation low
Restart inverter. If the error still persists, contact
the distributor
W025 Battery voltage high Battery voltage is nearing the high limit
W026 Battery voltage low Battery voltage is nearing the low limit
W027 Battery open
Check the battery for voltage via multimeter.
Ensure all wires are correctly installed to inverter
and battery
W028 Inverter overload Inverter is running beyond max. output
W029 Inverter voltage high
Restart the inverter. If error persists, contact the
distributor
W031 Inverter VDC high
Restart the inverter. If error persists, contact the
distributor

EG4 6000XP Specifications

General

Nominal DC Voltage	48V
Maximum DC Voltage	500V
Maximum Continuous Output Power	6000W
Frequency	60Hz
Model	EG4-6000XP
Peak Power	12000W
Protection Features	Over Voltage, Over Load, Over Temperature, Short Circuit
Cooling	Fan
