EG4 6000XP User Manual

1
1. TECHNICAL SPECIFICATIONS
AC INPUT DATA
NOMINAL AC VOLTAGE
120-240VAC
FREQUENCY
50/60Hz
MAX. CONTINUOUS AC CURRENT
37.5A @ 240VAC
MAX. AC INPUT POWER
9000W
AC BYPASS (GRID | GENERATOR)
50A | 50A
AC OUTPUT DATA
OUTPUT VOLTAGE
120/240VAC
OUTPUT FREQUENCY
50/60Hz
MAX. CONTINUOUS OUTPUT CURRENT @ 240V
25A
MAX CONT. LINE WATTAGE
3000W
NOMINAL POWER OUTPUT
6000W
SURGE CAPACITY
12,000W for ≈3.5 seconds | 11,000W for ≈5 seconds
POWER FACTOR VALUE
0.6 – 1
OPERATING FREQUENCY
50/60Hz
THD (V)
<3%
SWITCHING TIME
<15ms @ Single / <30ms @ Parallel
PV INPUT DATA
NUMBER OF MPPTS
2
INPUTS PER MPPT
1
MAX. USABLE INPUT CURRENT
17/17A
MAX. SHORT CIRCUIT INPUT CURRENT
25/25A
DC INPUT VOLTAGE RANGE
100-480 VDC
UNIT STARTUP VOLTAGE
100 VDC ± 10 VDC
MPP OPERATING VOLTAGE RANGE
120-385 VDC
NOMINAL MPPT VOLTAGE
320 VDC
MAXIMUM UTILIZED SOLAR POWER
8000W (4000W per MPPT)
RECOMMENDED MAXIMUM SOLAR INPUT
10000W (5000W per MPPT)
EFFICIENCY
MPPT EFFICIENCY
99%
BATTERY CHARGING EFFICIENCY
93%
BATTERY DISCHARGING EFFICIENCY
93%
IDLE CONSUMPTION (STANDBY MODE*)
W/ PV
<30W
w/ Battery
≈50W
w/ AC
<50W
BATTERY DATA
TYPE
Lead-acid/Lithium
MAX. DISCHARGE CURRENT 140A
MAX. CHARGE CURRENT 125A**
NOMINAL VOLTAGE 48 VDC
BATTERY VOLTAGE RANGE 46.4-60 VDC (Lithium); 38.4-60 VDC (Lead-Acid)
REC. BATTERY CAPACITY PER INVERTER >200Ah
HIGH DC CUT-OFF VOLTAGE 59 VDC (Lithium) | 60 VDC (Lead-acid)

EG4 6000XP Specifications

General

Nominal DC Voltage	48V
Maximum DC Voltage	500V
Maximum Continuous Output Power	6000W
Frequency	60Hz
Model	EG4-6000XP
Peak Power	12000W
Protection Features	Over Voltage, Over Load, Over Temperature, Short Circuit
Cooling	Fan
