Operating manual - Fan CF-C Safety rules
2004930 10.19/0.2 www.elektror.com 17 of 84
EN
Marking with warning labels according to ANSI
01
Warning against electricity
The symbol warns against a risk from
dangerous electricity.
On the terminal box of
electric motor
02
Warning against hot surface
The symbol warns against thermal risk
– hot surface burns.
On the housing and bearing
of the fan
2.3 Fan safety systems
2.3.1 Protective measures separating persons from the device
Guards
Touch guards
hub seal / cooling disc and clutch
Fan with protective elements
The rotating parts of the fan, such as the bearing shaft,
clutch and cooling disc are protected by touch guards.
The version with a single pedestal bearing is also
equipped with an additional shaft cover.
