Mounting, installation and connection Operating manual - Fan CF-C
36 of 84 www.elektror.com 2004930 10.19/0.2
EN
In addition, if the fan is located in enclosed spaces, the following rule
should be followed:
Sufficient ventilation should be provided. The heat delivered to the
environment should not cause exceeding the acceptable room
temperature.
In addition, if the fan is located outside, please follow the following
rule:
Electrical components, e.g. electric motor, must be protected
against the effects of weather conditions.
6.5.2 Installation location
Steel foundations, point and concrete foundations will prove themselves as the construction of
the fan base, guaranteeing the fan operation in conditions of protection against shocks,
vibrations and twisting. In addition, it is required that the design of the fan base provi
des for
axial alignment of the fan in the horizontal and vertical axis and secure attachment.
The fan should be designed with a sufficient minimum distance from the walls and other
elements.
Check the dimensions of the foundations based on the dimensional drawing of the fan and the
foundation design.
Observe the recommended ambient conditions of the fan and make sure that:
sufficient space has been provided for tool changing, installation, maintenance and repair
work.
sufficient space has been provided f
or the flow and outflow of the air to cool the drive motor.
−
sufficient fan protection is provided against solar radiation.
Installation materials, such as compensating plates, fastening screws, etc., are also available
from the manufacturer.
s to be aligned when placed on the foundation. To this end appropriate
measuring instruments, tools, pressing screws and metal spacers should be used.
If the fan is placed in a chemically aggressive atmosphere or in the open air, use stainless
steel spacers.
6.5.2.1 Mounting
Mounting the fan without vibration silencers on a steel structure
1. Place the fan at its destination.
2. The fan should be levelled.
If necessary, use sheet metal spacers.
3. Fasten the fan with hexagon bolts.
The correct tightening torques in chapter 11.1 "Tightening torques for fastening bolts" must
be observed.
Result:
The fan is mounted and installed at the destination.
