Operating manual - Fan CF-C Mounting, installation and connection
2004930 10.19/0.2 www.elektror.com 41 of 84
EN
When making the electrical connection of the fan, comply with the regulations and
connection conditions issued by the local energy supplier.

Connection data is included in the wiring diagrams that form part of the
technical
documentation.
Check that the voltage and frequency of the mains correspond to the voltage and frequency
values on the nameplate.

Follow the manufacturer's electrical documentation and use the information available in it
in a professional m
anner.
6.6.2 Earthing
Earthing lugs connectors
[general presentation]
Safe operation of the fan requires earthing lugs according to the rules
in force at the place of installation.
Make sure that the earthing conductor is of sufficient diameter.
Earthing lugs
quality requires inspection by an authorized facility.
6.6.3 Connection of monitoring devices
The fan is optionally equipped with monitoring systems.
6.6.3.1 Temperature monitoring
Temperature monitoring of
rolling bearings
Temperature sensors are responsible for monitoring the temperature
of the bearings.
Temperature sensors measure the temperature values at rolling
bearings.
6.6.3.2 Rotation speed monitoring
Rotation speed monitoring
The pulse shield, mounted at the end of the shaft on the drive side, is
responsibl
e for monitoring the speed. The encoder collects the
impulse for further processing.
