3.6 Technical Data
Mechanics
Case external dim. D/H (approx. mm)
600 / 610
Cleaning machine external dim. W/D/H
(approx. mm)
600 / 590 / 610
Weight incl. media tanks (approx. kg)
39
Number of media tanks (pcs.)
4
Working volume per media tank (l)
2.5
Exhaust air connections
2 x DN6 (passive)
Electronics
Mains voltage variant (V AC / Hz)
230 / 50/60
Mains voltage variant (V AC / Hz)
115 / 60
Mains voltage variant (V AC / Hz)
100 / 50/60
Mains input fuse
2 x T4A / 250 V
see rating plate
Mains cable cross section
3 x 1.0 mm²
Switchable ultrasound frequencies (kHz)
40 / 80
Maximum total power consumption (W)
220
Effective ultrasound power (W),
can be regulated 30% - 100%
50
Power consumption in standby (W)
20
Spinning mode speed range
freely adjustable up to max. (rpm)
1400
Cleaning / rinsing mode rotation speed
range (rpm)
1 - 20
Oscillation / vibration frequency rate (1/s)
1 – 14
Oscillation / vibration mode deflection (°)
1 – 60
Operation sound pressure level
1
(LpAU)
< 70 dB
Accessories
Individual basket external dimensions D/H
(approx. mm)
80 / 10 or 64 / 12
Number of individual baskets in the basket
holder
5 or 3
Maximum load, complete cleaning basket
(all individual baskets together) (approx. g)
100 or 60
Movement holder maximum movement
capacity (pcs.)
12
Activated carbon absorption unit
passive
1
measured maximum sound pressure level at 1 m distance
