Before the initial commissioning
© Elma Schmidbauer GmbH BA_Elmasolvex_VA_EN_Vers.05.2018
4.4 Filling media tank
There are 4 media tanks for the respective cleaning and rinsing
media located in the bottom area of the cleaning machine.
Fill the media tanks with the cleaning and rinsing media
recommended for them (Chapter 8).
The individual media tanks must be filled with cleaning or
rinsing solution according to the position in the cleaning
machine.
Removable labels are attached to the media tanks for individual
assignment and recognition of the filled media (Fig. 4.4.3.E).
For recognition of the respective position, there are markings on
the case and the support surface under the media tanks
(1-2-3-4).
Media tank in position #1: Cleaning medium
Media tank in position #2: Rinsing medium
Media tank in position #3: Rinsing medium
Media tank in position #4: Rinsing medium
Fig. 4.4.1 Illustration of the positions of the media tanks
All 4 media tanks must be filled with suitable operating
materials to be able to put the cleaning unit into operation.
Operation with unfilled or missing media tanks results in
unsatisfactory cleaning results or automatic abortion of the
cleaning process.
Positions of the
media tanks
Never operate with
unfilled or missing
media tanks!
#1
#2
#3
#4
