ELNet GR/PQ - Page 22

22
Insert the lead from side “K” of the Current Transformers of Line
1 through the bottom of the CT core I 1A, (top left looking from
back), of the ElNet Energy & Powermeter .
ARNING
Repeat the procedure for Line 2 and Line 3 (In ElNet PQ repeat
also for Neutral Line I N ).
Connect the rest of the connections to the ElNet Energy &
Powermeter by means of terminal connector plugs.
The Rear Panel (See Figure 2.7.) has all connections printed and
are simple to follow. (See table 2-1 for connections)
• Ensure the leads from leg “K” of the Current
Transformer on Line 1 pass through the bottom of
CT core I1A.
• Ensure the other end of the lead emerging from the
top of C T core I 1A is connected to leg “L” of the
Current Transformer on Line 1
WARNING!
Never allow an open circuit between the two Current
Transformers.
