If it is a new installation, the ratio will show 5 A:5 A .
11 Click “Enter”, the Insert Value screen appears.
Figure 4.6. Insert Value
12 Use Button “F3” or “F4” to move the cursor left or
right and Button “F1” or “F2” to decrease or
increase the value + or -.
13 To save Click “Enter”.
14 To cancel Click “Back”.
4.2
Electrical Connection Check
To avoid any problems arising from incorrect Voltage
Connections or accidental reversal of Current
Transformer Connections, it is necessary to perform a
Phase Order Check before continuing.
