5.11 Power Quality
Poor Harmonics could invoke a fine and damage to
the electrical system and can be improved by adding
filters.
The
ElNet
Energy & Powermeter
GR Model
is capable of
displaying Harmonics in Wave Form Graph, Harmonics Bar
Graph, Harmonic Tables and Total Harmonic Distortion for
Voltage and Current.
5.11.1 Wave Form Graphs
To display Wave Form Graphs
1 From Main Menu scroll to
Power Quality
.
2 Click “Enter”, the Power Quality screen appears.
Figure 5.13. Power Quality
3 Scroll to Wave Form Graphs.
