4.1 Settings for Current Transformer
To set or change settings for Current Transformer
The most important setting necessary for the proper
functioning of the
ElNet
Energy & Powermeter is
the Current Transformer setting.
The cross section of the leads to the current Transformer
must be compatible to the power of the current
transformer. We recommend a power transformer with at
least 3VA and the length of the wiring of the transformer
no longer than 3m.
1 From Main Menu scroll to Technical Menu.
2 Click “Enter” the Check Password screen appears.
Figure 4.1. Check Password
