5.11.6 EN50160 event monitoring and Wave
records
When a power quality event occurs (as specified in the
EN50160 standard), Elnet PQ stores the record of it in its
memory. This record can be downloaded to the PC later on
for detailed analyze.
Before starting the EN50160 events record mode, the nominal
voltage range must be defined:
1 Access the Technical Menu (see chapter 4.1).
2 Scroll to Next and click "Enter".
3 Scroll to PQ Parameters and click "Enter".
4 The PQ Parameters screen appears.
Figure 5.22. PQ Parameters.
5 Scroll to Set V Nominal.
