9.7 Communication with UniArt Software
CONTROL APPLICATIONS Ltd propriety software, “UniArt” is
used to Read and Write Registers of the
ElNet
Energy &
Powermeter
.
Each Item number in the Registers Table is a
unique field containing information. The UniArt software
manages each Item number as a parameter.
Refer to the UniArt manual how to set up parameters.
To read fields using UniArt
1 Find the reading required in the MODBUS Registers
Table
2 Note the Item Number from the Registers Table
3 Go to the correct File number
Because File capacity in UniArt is limited to 128
parameters, the information contained in the
ElNet
fields
is stored in several files.
File number is determined by the Item number
File
#
0 contains Item number 1 - 128
File
#
1 contains Item number 129 – 256
File
#
2 contains Item number 257 – 384
File
#
3 contains Item number 385 – 512
4 Go to the correct Point number within that file
Point number is determined by the formula:
Item number – [FILE X 128] = Point Number
